Motion sensor P1 detects human movement and ambient lighting conditions. If people move in the detection area or the ambient light level changes, the motion sensor will send a notification to the Aqara Home application through the connected Aqara ZigBee 3.0 hub or other devices.

Configurable detection timeout

Finally, detection timeout can be adjusted without hardware modification. Simply set any time from 1 to 200 seconds, confirm by pressing a button on the device, and the P1 will no longer freeze for a minute like before. (Please note: Reducing detection latency will result in shorter battery life.)

Battery life 5 years

Thanks to energy-saving technologies and advanced batteries, the P1 motion sensor can now achieve a record battery life of five years, making it last long even in the event of ultra-cold temperatures or lightning-fast detection failures.

Universal Compatibility

Compatible with the most popular smart home ecosystems. HomeKit, Alexa, IFTTT and others are supported. Matter support will be available as an over-the-air update to Aqara hubs once the specification is officially released.

Field of view 170°

Ultra-wide viewing angle: 170° at a distance of up to 2 meters and 150° at a distance of up to 7 meters. What's more, thanks to the versatile 360-degree viewing angle stand, you can adjust the viewing angle so that the camera only captures movement in the desired area (for example, near the bed or sink).

Adjustable sensitivity

The user can adjust the sensitivity of the sensor. Three sensitivity modes (high, medium and low) determine the distance at which the sensor is triggered, which helps reduce false alarms and makes installation more flexible.

Built-in light sensor

The P1's built-in light sensor allows for more precise lighting control. For example, turn on the lights only in the dark and when motion is detected to save energy and extend the life of the lamps.

Smart Home Automation

A motion sensor is an integral part of most smart home automation systems: set up IF conditions as well as THEN actions, and many routine tasks, such as turning on the lights, opening the curtains or controlling the TV, become automated**.

Local and remote alarm

With the Aqara Home Alert System, the P1 motion sensor can become a reliable security device: set the Away mode in the app and enjoy constant monitoring, local sound and light alarms, and cloud notifications when motion is detected. Or use it in HomeKit or other supported systems for the same purpose.

ZigBee 3.0 protocol

Enjoy the benefits of the fastest, most stable, and energy-efficient smart home technology. Increased stability and compatibility (more standardized protocol), longer support and more features.

Preparing for the future through OTA

The sensor now supports OTA updates, meaning new features and fixes can be added after the product is released.

For the device to work in the ecosystem, a Hub is required.

Model: MS-S02

Detection Angle: ≈170°

Detection distance: ≈7m

Color: white

Battery: 2x CR2450 (included)

Wireless protocols: Zigbee 3.0

Dimensions: 33.1×33.1×41.6 mm

Operating temperature: -10°C ~ 55°C (14°F ~ 131°F)

Operating humidity: 0~95%RH, non-condensing

Zigbee operating frequency: 2405–2480 MHz

Maximum Zigbee output power ≤ 13 dBm
